GS-CL Series
GS‑CL Series is Glorystar’s next‑generation, ultra‑long‑format, high‑power fiber laser cutter built for heavy‑duty, large‑scale metal cutting with modular flexibility, advanced automation, and industrial‑grade durability
Description
The Glorystar GS‑CL Series is a line of ultra‑large format, gantry‑type fiber laser cutting machines designed for oversized sheet metal and structural components.
Features
Extra-large segmented bed design with fully customizable cutting dimensions to suit your needs.
Unmatched Z-axis travel and height capacity - cuts square tubes and channel steel up to 400mm with ease.
Optional bevel cutting feature available for enhanced versatility.
Industry-exclusive smart collision detection system for advanced operational safety.
SPECIFICATIONS
| GS-13030CL | GS-16035CL | GS-25035CL | |
|---|---|---|---|
| Max. material width (mm) | 13000×3000 43×10ft bevel cutting: 12500×2500 41×8ft | 16000×3500 52×11ft bevel cutting: 15500×3000 49×10ft | 25000×3500 82×11ft bevel cutting: 24500×3000 80×10ft |
| X axis travel (mm) | 3050 / 10ft | 3550 / 11.7ft | 3550 / 11.7ft |
| Y axis travel (mm) | 13050 / 42.8ft | 16050 / 52.7 | 25050 / 82.2ft |
| Z axis travel (mm) | 290 (bevel cutting: 450) / 11.4in (bevel cutting: 17.8in) | 290 (bevel cutting: 450) / 11.4in (bevel cutting: 17.8in) | 290 (bevel cutting: 450) / 11.4in (bevel cutting: 17.8in) |
| X/Y positioning accuracy | ≤0.03mm/m / 0.00118in/39.4in | ≤0.03mm/m / 0.00118in/39.4in | ≤0.03mm/m / 0.00118in/39.4in |
| X/Y repeat positioning accuracy | ≤±0.02mm / 0.00079in | ≤±0.02mm / 0.00079in | ≤±0.02mm / 0.00079in |
| Max. synthetic positioning speed | 50m/min / 164ft/min | 50m/min / 164ft/min | 50m/min / 164ft/min |
| Max. acceleration | 1.2G | 1.2G | 1.2G |
| Drive method | X/Y axis: Rack and pinion, Z axis: Ball screw | X/Y axis: Rack and pinion, Z axis: Ball screw | X/Y axis: Rack and pinion, Z axis: Ball screw |
| Min. setting unit | 0.001mm / 0.00003937in | 0.001mm / 0.00003937in | 0.001mm / 0.00003937in |
| Floor area of machine tools (mm) | 21000×11500 69×38ft | 25000×12000 82×39ft | 34000×12000 112×39ft |
| Host volume (mm) | 18700×5600×2600 61×18×9ft | 22500×6300×2600 74×21×9ft | 31500×6300×2600 103×21×9ft |
| CNC system | BOCUH | BOCUH | BOCUH |
| Monitor | 27" LCD | 27" LCD | 27" LCD |
| Transfer method | Refer to the following process parameter table | Refer to the following process parameter table | Refer to the following process parameter table |
| Max. load-bearing capacity of worktable (tons) | 20 / 44093lbs | 35 / 77643lbs | 55 / 121753lbs |
| Total installed power consumption | 10000W 80KW | 10000W 80KW | 10000W 80KW |
| Total installed power consumption | 12000W 100KW | 12000W 100KW | 12000W 100KW |
| Total installed power consumption | 15000W 120KW | 15000W 120KW | 15000W 120KW |
| Total installed power consumption | 20000W 150KW | 20000W 150KW | 20000W 150KW |
| Total installed power consumption | 30000W 200KW | 30000W 200KW | 30000W 200KW |
| Total installed power consumption | 40000W 250KW | 40000W 250KW | 40000W 250KW |
| Power requirements | AC380V , 50Hz ; 3P+N+PE | AC380V , 50Hz ; 3P+N+PE | AC380V , 50Hz ; 3P+N+PE |
| Total power protection level | IP54 | IP54 | IP54 |
