Hwacheon Cutex 180BL SYMC
Hwacheon Cutex 180BL SYMC features CUTEX-180 6/8-inch turning centre with Ø545–Ø700 mm swing, Ø300–Ø350 mm max cutting diameter and turn-mill/Y-axis options, designed for accurate and reliable production turning.
Description
Hwacheon Cutex 180BL SYMC is a turning centre built around CUTEX-180 6/8-inch turning centre with Ø545–Ø700 mm swing, Ø300–Ø350 mm max cutting diameter and turn-mill/Y-axis options. It is intended for automotive, hydraulic and general engineering work, combining a rigid structure with production-focused controls and tooling to support accurate, repeatable work.
The machine is suitable for workshops and manufacturers that need reliable output across batch or production environments.
Features
Key Features
- 6"–8" chuck horizontal CNC turning centre
- Highly rigid roller linear guideways on all axes
- Upgraded main spindle motor for improved performance
- High-power turn-mill capability in its class
- Extended maximum bar capacity for increased flexibility
- Supports up to 24 tools on the index turret
- Lightweight sliding door for improved operator convenience
- Chip management design helps prevent chip accumulation
- 90° rotating operator panel for enhanced ergonomics
- Optional software packages for improved operation and machining efficiency
- Front-mounted coolant tank for easy maintenance access
- Standard coolant level sensor
- Easy-access maintenance covers
- External coolant block design reduces the risk of turret coolant leakage
- Designed for high productivity, reliability and ease of maintenance
SPECIFICATIONS
| Swing Over Bed | Ø545mm |
| Max. Cutting Length | 328mm |
| Spindle Power | 15/11kW |
| Spindle Speed | 6000/4500rpm |
| Number of Tool Stations | 12MC (24 Pos. index) |
| Rapid Speed | 36/36/10m/min |
| Turn Mill Motor Power | 5.5/3.7kW |
| Turning Length, Max. | 528mm |
