Zopo SVB1890
The ZOPO SVB1890 Vertical Machining Centre combines a large machining envelope, high-rigidity construction, and flexible spindle configurations for precision machining of large industrial components.
Description
The ZOPO SVB1890 Vertical Machining Centre is a heavy-duty CNC machining solution from the SV Series, designed for large-scale precision machining and demanding metal-cutting applications. Engineered for industries such as aerospace, automotive, mould and die manufacturing, and heavy engineering, the SVB1890 combines a rigid machine structure, powerful spindle options, and advanced motion technology to deliver exceptional productivity and accuracy.
Built around an integral box-type bed and reinforced arched column structure, the machine provides outstanding rigidity, vibration resistance, and long-term stability during heavy machining operations. High-load roller linear guideways and an enclosed spindle box design further enhance positioning accuracy and cutting performance.
The SVB1890 is available with belt-driven, direct-drive, or gear-head spindle configurations, allowing manufacturers to optimise performance for specific production requirements. Combined with an automatic tool changer and efficient chip evacuation system, the machine is designed to maximise uptime and productivity in continuous manufacturing environments.
Features
- Heavy-duty vertical machining centre design
- Integral box-type bed construction
- Reinforced arched column structure
- High-rigidity roller linear guideways
- Available with belt-drive, direct-drive, or gear-head spindle options
- Large-capacity machining envelope
- Closed spindle box design for improved accuracy
- Dual integrated chip screw system
- Efficient chip evacuation for continuous production
- Disc-type automatic tool changer
- Excellent vibration resistance and stability
- Suitable for heavy-duty metal cutting applications
- Designed for aerospace, automotive, and mould manufacturing
- Optimised for high-precision machining
SPECIFICATIONS
| Specification | SVB1890 |
|---|---|
| Machine Type | Vertical Machining Centre |
| Series | SV Excellent Models Series |
| X-Axis Travel | 1800 mm |
| Y-Axis Travel | 900 mm |
| Z-Axis Travel | 800 mm |
| Worktable Size | 1900 × 900 mm |
| Spindle Options | Belt Drive / Direct Drive / Gear Head |
| Maximum Spindle Speed | 6000 – 10000 rpm |
| Rapid Traverse Rate | 20 – 24 m/min |
| Guideway Type | Roller Linear Guideways |
| Tool Changer Type | Disc-Type ATC |
| Chip Evacuation System | Dual Built-In Chip Screws |
| Spindle Box Design | Closed Box Structure |
| Machine Structure | Integral Box Bed with Arched Column |
| Application Type | Heavy-Duty Precision Machining |
| Typical Industries | Aerospace, Automotive, Mould & Die |
